8310 Walkie Pallet Truck Electric Pallet Jack
-
-
ACR System
Delivers energy efficiency and productivity for longer battery life, quick and smooth acceleration, and less downtime.ACR System -
Advanced Engineering
Thoughtfully designed with fewer and longer-lasting components that require less maintenance, sourced from world-class suppliers.Advanced Engineering -
Battery Discharge Indicator
Battery Discharge Indicator with lift interrupt minimizes the possibility of component and battery damage due to operation at low voltage levels.Battery Discharge Indicator -
Sturdy Forks
Ideal for heavy-duty dock applications; available in single and double lengths with capacities up to 8,000 lbs.Sturdy Forks -
Peak Performance
Programmable performance features deliver speed and precision, with settings that can be tailored to the operator and the application.Peak Performance
Pallet Handling Workhorse
The 8310 walkie pallet jack is a durable workhorse designed to load and unload trailers with ease in heavy-duty applications. With ergonomic controls, sturdy forks and durable construction throughout, your operators will move pallets with ease. Customize with extreme environment and cold storage packages.- Battery: 24 volt
- Capacity: 6,000 lbs. or 8,000 lbs.
- Fork Length: Available in multiple lengths and widths
- Loaded Travel Speed: 3.9 mph
- Unloaded Travel Speed: 3.9 mph
Built to Perform
-
Lift and Go Programmability
Raymond’s exclusive programmable feature lets you reduce travel speed to train operators to travel with forks elevated to prevent unnecessary wear to the undercarriage over dock plates. -
Designed for Maximum Workload
From the heavy-duty undercarriage to the rugged polymer cover that won’t rust, fade or dent, the 8310 walkie pallet jack is built with the right materials for the job. -
Smarter Components
Stand up to tougher applications longer — from Hall Effect Sensors, which replace potentiometers that wear and require replacement, to electric brakes that minimize moving parts.
-
Efficient by Design
Raymond sources best-in-class components, then fine-tunes and calibrates them for peak performance, for longer component and vehicle life. A lightweight yet resilient cover and a durable drive motor are key factors in our efficient performance. -
Greater Energy Efficiency
The ACR System and right-sized drive motor deliver longer battery run time, fewer battery changes over the course of a shift, less batteries required overall, and lower costs for your operations.
-
Comfortable Handle
The intuitive control handle is engineered to fit a wide range of operator sizes with easy-to-reach controls. -
Thumb Wheel Controls
Conveniently located thumb wheels control the truck’s direction and speed when traveling both fork first and tractor first. This allows one-handed operation for forward, reverse, lift, lower or horn.
-
Easy to Maintain
CanBus technology in the handle eliminates up to 40% of wiring, composite bushings never require greasing, the drive tire can be easily changed out in just minutes, and the durable yet lightweight cover provides convenient service access. -
Heavy-Duty Components
From the strong tail fork castings to the steel reinforced battery box and durable drive motor, the 8310 walkie pallet truck is built with heavy-duty, long-lasting components that are engineered to handle your heaviest loads. -
Stainless Pins
Ensure longer component life and easier maintenance. Rust and corrosion are common with standard steel pins, which can greatly impact serviceability of the undercarriage. Raymond pallet jacks feature stainless pins, which in many cases extends the life of the bushings and undercarriage assembly.
-
Smooth Pallet Entry
Tapered forks are designed for easy pallet entry and exit, for a smoother transition in and out of pallets, with a streamlined fork thickness for better clearance. -
Smooth, Precise Control
Maneuver busy dock areas and in trailers with ease and smooth, controlled operation at all speeds. -
Industry-Leading Speeds
Programmable travel speeds and quick acceleration boost operators' productivity, allowing them to move more pallets per hour.
-
Accessory Bar
Interfaces with any RAM-mounted accessories to put additional tools at the operators' fingertips; available with optional work light and fan. -
PIN Code Pad
The optional personal identification number (PIN) code pad provides password protection for additional security. Store up to 10 different passwords to prevent unauthorized operation. -
Large Storage Tote
An optional tote helps keep work tools organized and at your operators' fingertips for added convenience and productivity throughout the shift. -
Extreme-Environment Corrosion Protection
Hot-dip galvanization of the truck frame, battery box, forks and undercarriage extends the life of trucks in wet, corrosive environments. Ideal for processing applications or other environments subject to harsh conditions or frequent washdowns. -
Spring-Loaded Casters
Ensure superior load handling — smooth, controlled operation and enhanced operator comfort when transporting a load.
-
Truck Loading and Unloading
Improve your dock operation productivity with Raymond pallet jacks. Our electric pallet trucks are ideal for breakdown of pallets removed from trailers, long runs to P&D stations, or a combination of both, offering a wide variety of operating positions that are engineered to enhance driver comfort and minimize fatigue for this specific application.
-
Processing Environments
Trucks used in processing applications where there are wet, caustic and briny conditions can be protected from moisture and can flush contaminants with Raymond's extreme-environment corrosion package (EECP).
-
UL EE Applications
This lift truck complies with Underwriters Laboratories (UL) 583. Raymond Type E and EE trucks are UL tested and UL-certified and designed and manufactured to operate in classified locations as defined in NFPA 505.
-
8000 Series Pallet Trucks Video
From the heavy-duty undercarriage to the rugged polymer cover that won't rust, fade or dent, Raymond pallet jacks are built with the right material for the job. With fewer and longer lasting components that require less maintenance, and engineered to handle high volume dock work, horizontal transportation and low-level order picking with ease.
